When we talk about Abaqus, “Token” always comes together. What’s “Token”?

NSS
NSS

“Token” (“Token-based license model”), is a way of licensing of Abaqus.

You can buy certain number of “Token” licenses to use Abaqus.

NSS
NSS

Let’s see more details with some examples and exercises.

What is “Token” in SIMULIA/Abaqus?

Token (=Token-based license model) is a way of licensing of Abaqus.

    For example: QAX (seat) + QXT  (token)” is one of the popular offers of Abaqus.

  • How do you count for each:
    • QAX* 1 seat (to use GUI of Abaqus/CAE pre-processing, viewing result)
    • QXT* 5 tokens (to use Abaqus Solvers (=Products) for calculation & simulation)

            (Remarks: Those are sold in pairs, not individually)

How to define the necessary numbers of Token?

It depends on 1) and 2).

1) Depend on what Abaqus Solvers (=Products) you want to use. (The higher-end model of Abaqus Solvers (=Products) you need, the more tokens are required.)

    For example:

  • 5 tokens are required to use Abaqus/Standard and Abaqus/Explicit
  • 10 tokens are required to use Abaqus/AMS and Abaqus/AMS (Standard)

2) Depend on Hardware spec (the number of CPU) for calculation. (The faster calculation with higher spec of server, the more tokens are required.)

    For example:

  • 8 tokens are required to use Abaqus/Standard and Abaqus/Explicit with  calculation server with 4-CPU
  • 14 tokens are required to use Abaqus/Standard and Abaqus/Explicit with  calculation server with 12-CPU

Let’s try calculating the numbers of Token!

Question: How many tokens are required to meet the below conditions “1.” and “2.”?

→ Condition:

  1. You need to make Impact analysis or Drop test analysis.
  2. You use a calculation server with 8-CPU for Abaqus.

→ Calculation steps:

  • Step1. To meet “1.”, you need “Abaqus/ Explicit Package”.
  • Step2. To use “Abaqus/ Explicit Package”, at least 5 tokens are required.
  • Step3. To use Abaqus/ Explicit Package with server with 8-CPU (=“2.”), 12 tokens are required.

Answer: 12 tokens
